Motor de vehículo EURO V
| Model | CA6DL2-29E5 | CA6DL2-31E5 | CA6DL2-33E5 | CA6DL2-35E5 | CA6DL2-37E5 |
| Type | 4-cylinder in-line, direct injection, turbocharged&intercooling, common rail | ||||
| Bore×Stroke (mm) | 112×145 | ||||
| Valves/cylinder | 4 | ||||
| Displacement (L) | 8.6 | ||||
| Rated power (kW) | 218 | 231 | 249 | 261 | 279 |
| Net power (kW) | 215 | 228 | 246 | 258 | 276 |
| Rated speed (r/min) | 2100 | ||||
| Maximum torque (Nm) | 1250 | 1250 | 1350 | 1500 | 1550 |
| Maximum torque speed (r/min) | 1300～1500 | ||||
| Fuel consumption (g/kW·h) | 192 | ||||
| Noise dB (A) | ≤ 94 | ||||
| Technical Route | SCR | ||||
| Emission Compliant (TAS) | EURO V | ||||
| Net Mass (kg) | 870 | ||||
| Length×Width×Height (mm) | 1308×778×996 | ||||
